Transformer varnish

Air-drying and baking insulating varnishes for low and medium voltage transformers, reactors and variacs. Made in Istanbul since 1988.

A three-phase dry-type transformer impregnated with air-drying varnish

What is transformer varnish?

Transformer varnish is an insulating varnish applied to transformer windings that protects the winding against moisture, dust and contamination. As it hardens, it fixes the wires in place, reduces noise and vibration in operation and strengthens the winding insulation.

At a glance

What is transformer varnish?

Transformer varnish is the electrical insulating varnish applied to transformer coils after winding. It penetrates between the wires and bonds them to each other and to the core, keeps out moisture and dust, reduces vibration and hum in service, and raises the winding's resistance to heat and electrical stress. It is used most on low and medium voltage transformers, shunt reactors, voltage regulator transformers, chokes and variacs.

Types of transformer varnish

Air-drying transformer varnish: OR-105

No oven needed; it dries at room temperature. OR-105 is a high-solids class F (155 °C) transformer insulating varnish. It is applied by dipping or spray gun and thinned with T-100. It suits shops without an oven, repair work and parts too large for an oven.

Baking transformer varnish: OR-305

Cured in an oven, it leaves a hard film that resists chemicals and field conditions. OR-305 is a class H (180 °C) baking transformer insulating varnish. It can be applied by dipping, VPI (vacuum pressure impregnation) or spray gun. It suits series production, dry-type transformers and windings that run hot.

Complementary products

Variac varnishes and variac pastes, pole and insulation paints, transformer exterior paints and insulating topcoats are available from the same supplier.

How to choose a transformer varnish

How to apply transformer varnish

  1. Clean the winding and preheat it to drive out moisture. A warm winding takes varnish in better.
  2. Thin the varnish only with its own thinner, at the ratio in the TDS. OR-105 is thinned with T-100.
  3. When dipping, keep the winding in the varnish until bubbles stop; for VPI apply vacuum first, then pressure; with a spray gun, work the varnish well between the wires.
  4. Let the excess drain; thick pools stay soft inside.
  5. Air-dry for the full time in the TDS, or follow the recommended temperature and time schedule for baking varnish.
  6. If needed, finish with an insulating topcoat against moisture and corrosion.

Common mistakes

A three-phase dry-type transformer impregnated with air-drying varnishTransformer winding and core, close-upA toroidal variac winding

Transformer varnishes

ProductBaseThermal classProperties and use
OR-105High solidsF · 155 °CTransformer insulating varnish; applied by spray gun or dipping, thinned with T-100
OR-305See TDSH · 180 °CBaking transformer insulating varnish; applied by dipping, VPI or spray gun

Technical information

UseLow and medium voltage (LV / MV) transformers, reactors, chokes, variacs
DryingAir-drying (OR-105) or baking (OR-305)
Thermal classF · 155 °C (OR-105), H · 180 °C (OR-305)
ApplicationDipping, VPI, spray gun
Complementary productsVariac varnishes and pastes, pole and insulation paints, transformer exterior paints

Drying time, viscosity and pack sizes are given in the product TDS.

Questions

What does transformer varnish do?

It bonds the winding wires to each other and to the core, protects against moisture and dust, reduces vibration and hum, and raises the winding's resistance to heat and electrical stress.

Should I choose air-drying or baking transformer varnish?

If you have an oven and run series production, baking OR-305 gives the hardest film and highest bond strength. Without an oven, for repairs or large parts, use air-drying OR-105.

Which class does a dry-type transformer need?

Dry-type and hot-running transformers usually need class H (180 °C) varnish. OR-305 is class H. Choose by the class on the transformer's nameplate.

Which transformer varnish is used for VPI?

Baking OR-305 is used for VPI (vacuum pressure impregnation). It can also be dipped or sprayed.

Which varnish is used in oil-filled transformers?

The winding works in hot transformer oil, so an oil-resistant varnish is needed. Send us the transformer type and operating temperature and we will suggest a product with its TDS.

What is transformer varnish thinned with?

Each varnish is thinned with its own thinner. OR-105 is thinned with T-100; ratios are in the product TDS.

Do you also make transformer exterior paint?

Yes. We also make transformer exterior paints and pole and insulation paints.

Let's choose your varnish

Tell us the motor type, the operating temperature and how you apply varnish; we will send the right product, its TDS and a price.
